Aja ha5-12g-t (ha5-12g-t-r0)
HA5-12G-T
12G-SDI to HDMI 2.0 Converter with Fiber Transmitter
• Convert an HDMI 2.0 input with up to 8-Channels of audio from the HDMI souror 2-Channel analog audio (RCA) to two 12G-SDI single link outputs with eight or two channels of digital embedded audio
• Analyzes HDR Infoframe data coming in over HDMI in accordanwith HDMI v2.0b/CTA-861-G
• Transmits two DA 12G-SDI signals on each SDI output, reducing cable runs when transporting 4K/UltraHD SDI
• Includes a single channel Fiber 12G LC transmitter, which extends 12G-SDI signals over long distans (10 km Single Mode)
• HA5-12G-T ships with FiberLC-1T-12G SFP installed
• Includes a DWP-U power supply and USB port for firmware updates
• Five year warranty
HDR
HDR, or High Dynamic Range, provides the ability to display a wider and richer range of colors, much brighter whites, and much deeper, darker blacks than standard signals allow. This gives your imagery a more ‘dynamic' look and allows for natural true to life colors to be communicated to your audien
HA5-12G provides this support for your 4K/UltraHD/HD HDR pipelines to HDMI compatible displays by generating HDR metadata in accordanwith HDMI v2.0b/CTA-861-G. HA5-12G also provides support for Hybrid Log Gamma (HLG) HDR displays over HDMI.
4K and UltraHD
Typical 4K signals use a resolution of 4096 x 2160 pixels while UltraHD signals measure 3840 x 2160. This differencan prevent some monitors from being used either in full 4K workflows or in UltraHD workflows. HA5-12G can compensate for these resolution differens, allowing UltraHD monitors to be used in 4K productions and viversa.
HA5-12G also supports High Frame Rate (HFR) inputs. 4K/UltraHD signals at 50 or 60 fps can be fed into HA5-12G and output at up to 60p for viewing with appropriate HDMI 2.0 capable displays.
12G-SDI Support
The 12G-SDI input on HA5-12G allows extremely high quality signal representation through to the HDMI output for use with large raster and deep color workflows where image quality is critical.
Audio Integration
Up to 16-Channels of embedded SDI audio are supported on input and can be passed to 8-Channel of embedded HDMI audio on the output with the ability to delay the audio from 0 to 7 frames for proper synchronization with the output video. Two channels of analog audio output allow direct external monitoring without the need to disembed the audio separately.
DSLR support
HA5-12G acpts progressive standard definition signals at 525p and 625p for compatibility with DSLR cameras, allowing the signal from those cameras to be easily incorporated into SDI workflows.
Universal Power Supply
All AJA Mini-Converters ship with a universal power supply that includes international plug connections for use around the world.
Compact and Portable
AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack or directly on a camera rig. A locking power connector can't accidentallyaus Kunststoffll loose and an optional P-TAP power cable allows for battery power in remote locations.
|
Technischedaten
AJA Quality - Guaranteed
All AJA Mini-Converters are covered by a five year warranty and AJA's advand replament policy. If a replament is nessary, AJA will ship a new unit immediately without the need to send the original unit back first, ensuring you are up and running again as quickly as possible.
