CG-500
HD/SD Graphics Character Generator
The Microsoft Windows™ based Datavideo CG-500 graphics, titling and character generator software is a powerful multi-layer, real-time solution for live programming and post production.
It is compatible with widely available professional video hardware and supports the lexible play-out of multiple playlists, even while titles are being created. CG-500 can be used by for SD or HD news, sports, weather forecasts and entertainment programming.
Minimum Requirements
Standard Definition
• Intel Core Duo 2.4 GHz
• Able to support Pixel/Vetex Shader Model 3.0 graphics card, or above,256MB graphics memory and 128 bit or above, NVIDIA stream prossors have 96 or above, ATI stream prossors have 480 or above
• 1 GB system memory
• 500 GB system hard disk
• 1280800 screen resolution monitor, or above
• Windows XP Professional SP2
Recommended
• Intel i3 3.0GHz or i5 2.8 GHz
• NVIDIA stream prossors have 192 or above, ATI stream prossors have 720 or above, 512MB graphics memory and 128 bit
• 2 GB system memory
• IT system hard disk
• 1440900 screen resolution monitor, or above
• Windows 7 32bit or 64bit Professional or Ultimate or above
High Definition
• Intel i5 Quad Core 2.8 GHz
• Able to support Pixel/Vetex Shader Model 3.0 graphics card, or above,512MB graphics memory and 128 bit or above, NVIDIA stream prossors have 192 or above, ATI stream prossors have 720 or above
• 2GB system memory
• 500GB system harddisk
• 1440900 screen resolution monitor, or above
• Windows 7 64bit Professional or above
Recommended
• Intel i7 2600 3.4GHz
• NVIDIA stream prossors have 336 or above, ATI stream prossors have 1120 or above, 1000MB graphics memory and 256 bit or above
• 4GB system memory
• 1T system harddisk
• 16801050 screen resolution monitor, or above
• Windows 7 64bit Professional or Ultimate
Features
Real-time graphic render, supports flexible play control of multiple playlists, real-time multi-layer play at the same time.
• High-Quality Render and GPU Effects including 3D PageCurl, Swirl, Explode and Linear Light
• All effects are keyframe-able
• Innovative group playing and text playing: by character, by line and by text, exclusive GPU dynamic texture
• Templates: including layout, CGlayout, Animation, Effect, etc.
• Modify on the fly: create and modify without interrupting the current playout
• Flexible Play List Control: 3 playlists, 1 subtitle and 1 quick play list each with sequenplay, arbitrary play, schedule time play or auto play
• Independent playlist hotkey control
• Real-Time data for text crawler objects, stock crawler objects, universal flip objects. These objects can be linked with kinds of external data sour(such as CSV file, text file, ODBC, etc) for real-time updating of graphic information
• External monitor displays title editing and playing through linking a single VGA
• 3D Stereoscopic Creating and Playing: side by side, top and bottom, line interleave output. Advand hardware supports 3D stereoscopic dual output of left eye and right eye (full colour, fill colour and alpha colour)
• Compatible with DeckLink HD Extreme 3D+ Card
• Windows Only
|
